SCHNEIDER ELECTRIC
Art.Nr: 15432848408907
Contactor, 3p+1NO, 4kW/400V/AC3, 9A, 24V DC – LP1K0910BD
Regular price
Regular price
€ 44,23
inkl. USt.
€ 36,86 exkl. USt.
€ 36,86 exkl. USt.
Unit price
Verfügbarkeit wird geladen …
Contactor, 3p+1NO, 4kW/400V/AC3, 9A, 24V DC – LP1K0910BD is backordered and will ship as soon as it is back in stock.
Contactor TeSys LP1K. 3-pole, 3 NO. Additional auxiliary contacts - 1 NO, rated operational power at AC-3, 400 V 4 kW, rated operational current Ie at AC-3, 400 V 9 A, coil 24 V DC. Dimensions (WxHxD) 45x58x57 mm, weight 0.225 kg. Category AC-3, AC-1, AC-4. Simple machine control in industrial, infrastructure and building applications. Easy-to-use interface for electronic devices (PLC). Certifications according to UL, CSA. Product standards according to
SCHNEIDER ELECTRIC
Art.Nr: 15432848408907
Regular price
Regular price
€ 44,23
inkl. USt.
€ 36,86 exkl. USt.
€ 36,86 exkl. USt.
Unit price
Contactor, 3p+1NO, 4kW/400V/AC3, 9A, 24V DC – LP1K0910BD is backordered and will ship as soon as it is back in stock.
Installation anfragen
Montage • Elektro • Inbetriebnahme
Wir bieten die Installation deiner Photovoltaikanlage durch unser Team sowie durch ausgewählte Partnerbetriebe an. Gemeinsam sorgen wir für eine fachgerechte Montage, Elektroinstallation und zuverlässige Inbetriebnahme.
Installation anfragen
Datenblatt
Hinweis: Der Link kann je nach Hersteller direkt einen Download starten.
Technische Parameter
Technische Parameter
| Depth | 57 mm | Height | 58 mm |
| Width | 45 mm | Suitable for series installation | No |
| Number of auxiliary contacts as N.C. contacts | 0 | Number of auxiliary contacts as N.O. contacts | 1 |
| Rated operational power at AC-4, 400 V | 2.2 kW | Rated operational current Ie at AC-4, 400 V | 6 A |
| Rated operational power at AC-3, 400 V | 4 kW | Rated operational current Ie at AC-3, 400 V | 9 A |
| Rated operational current Ie at AC-1, 400 V | 20 A | Type of electrical connection of main circuit | Screw connection |
| Number of N.O. contacts as main contacts | 3 | Number of N.C. contacts as main contacts | 0 |
| Type of voltage for actuation | DC | Rated control supply voltage DC | 24..24 V |
